Portable barbecue
Features and utilities:
• The prototype was made manually using few appliances to cut and to weld the pieces that comprise the product. Its body and tables are made of steel sheets, each 1 mm thick, with the last bar being covered by wood to isolate the heat. Finally, the legs are made of stainless steel tubes, 1.5 mm thick. Factors like a high temperature and external environment effects are those to determine the adequate thickness of the utilized materials
• It consists of a grill, a body, two tables/trays, two legs and four optional ones in addition
• It is a folding barbecue as shown in the first picture, and thus, can be easily transported (total weight is 5 kg)
• Two parts compose the legs of the barbecue, which allow a cook to choose its height by fixing the second segment if the greater height is desired
• The two tables can be extracted and used as a tray
• The grill is equipped with two handles covered by wood to allow the cook to remove it at anytime
• The “body” is completely closed to isolate the coal from the wind
